RSE 3 Series

The RSE 3 Series products are Type 1 & Type 2 (with filtering) and optional rotary disconnect SPDs that can be used at the service entrance and/or distribution panel level. This unit has an optional Advanced Monitor that includes a full-color LCD touchscreen display with a real-time voltage/current power quality monitor, event log with time & date stamp, embedded web page or SNMP communication, user-settable alarm thresholds, and percent protection remaining functions.

  • Metal cabinet enclosure NEMA 4
  • Modes: 7; Rating: 50/100/150/200 kA/mode
  • LED + Buzzer + RC contacts + Counter w/ Time and Date Stamp
  • Advanced full-color LCD with integrated webpage
  • View full Voltage/Current, Power Monitoring, and Download Events
  • Adjust the Date/Time
  • View Protection Status, System Information, Alarms & Thresholds
  • Event Log enables viewing event history, individual events, and statistics
  • Terminal wired or integrated disconnect option
  • 50kA – 200kA per mode
  • UL 1449 Listed
  • Stacked MOV Design
  • Sharing optimization increases current handling abilities
  • Low Voltage Protection Ratings
  • 20kA I-nominal Ratings
  • 200kA SCCRs
  • Advanced TOV/Surge Counter w/ Time & Date stamping
  • 10-year Standard Warranty
